Ibis Ripmo AF: The Aluminum Alternative with Premium Performance

The Ibis Ripmo AF (Aluminum Frame) takes the acclaimed performance of the carbon Ripmo and offers it in a more durable and affordable package. Designed to meet the demands of aggressive riders, the Ripmo AF brings modern geometry, top-tier suspension, and versatile features to a broader audience, without sacrificing any of the premium ride characteristics that Ibis is known for.

Metal Magic

• Durable Aluminum Alloy: The Ripmo AF is constructed from high-quality aluminum, delivering the same confidence-inspiring ride as its carbon counterpart but at a more accessible price point. This material choice makes it perfect for rowdier riders who push their bikes to the limit.

Modern Geometry

• Efficient Climbing, Confident Descending: The Ripmo AF features a steep 76-degree seat tube angle, positioning the rider centrally over the bottom bracket for efficient power transfer. The 64.9-degree head tube angle, paired with a 44mm reduced-offset fork, ensures stability at high speeds and precision on steep descents.

DW-Link Suspension

• Proven Performance: Ibis continues its long-standing partnership with suspension expert Dave Weagle, utilizing the dw-link suspension platform. This system offers an unparalleled balance of climbing efficiency and downhill capability, making the Ripmo AF a formidable contender on any terrain.

Air & Coil Compatibility

• Versatile Suspension Setup: The Ripmo AF’s progressive leverage rate makes it compatible with both air and coil shocks, giving riders the flexibility to choose their preferred suspension feel. Whether you want the linearity of a coil or the pop of an air shock, the Ripmo AF delivers a supple ride with enhanced traction throughout the entire stroke.

Tire Clearance

• 2.6 Tire Compatibility: Designed with modern wide-rim technology in mind, the Ripmo AF can accommodate tires up to 2.6 wide. This setup allows for ultra-low tire pressures, resulting in exceptional cornering traction and straight-line speed.

Sizing and Dropper Post Compatibility

• Customizable Fit: With its ultra-low standover height, the Ripmo AF allows riders to choose their frame size based on reach preference. The frame design also supports the use of long dropper posts, accommodating posts up to 213mm for taller riders.

Additional Features

• Removable ISCG05 Mount: The frame includes an optional ISCG05 mount for riders who need additional chain retention, with the flexibility to remove it if not needed.
• Lifetime Warranty: Ibis stands behind the Ripmo AF with a lifetime warranty, ensuring your investment is protected.

Specifications

• Frame Model: Ibis Ripmo AF (2022)
• Frame Size: XL
• Frame Color: Metal
• Rear Shock: DVO Topaz T3 Air, 210x55mm
• Headset: Cane Creek Forty
• Fork Model: Marzocchi Bomber Z1 Coil, 160mm Travel, 44mm Offset, Medium Spring
• Front Axle: Fox Kabolt, 15x110mm Boost
• Wheels: Ibis Send 1 (Front) & Send 2 (Rear) Aluminum Rims, Ibis Logo Hubs, 32H, Sapim D-Light J-bend Spokes
• Tires: Maxxis Assegai 29 x 2.5WT 3C MaxxTerra EXO+ TR, Tubeless
• Brakes: Shimano SLX BL-M7100/BR-M7120 4-Piston with 203mm (Front) and 180mm (Rear) Shimano Deore RT66 Rotors, 6-Bolt
• Drivetrain: Shimano SLX 12-speed (Shifters, Derailleur, Chain, Cassette), Shimano SLX FC-M7120 Crankset with 30T Chainring
• Cockpit: Ibis BFD Stem (50mm), Ibis 800mm Carbon Handlebar, Lizard Skin Charger Grips
• Seatpost: Bike Yoke Revive Dropper 213mm, Internal Routing
• Saddle: WTB Volt CrMo Medium
• Bottom Bracket: Shimano BB-MT800
• Chainrings: Shimano SLX SM-CRM75 30T
• Rear Axle: Ibis Thru-Axle, 12x148mm Boost
• Comes with: 200ml Stans Sealant

Conclusion

The Ibis Ripmo AF delivers the same award-winning performance as the carbon Ripmo, with the added durability and affordability of an aluminum frame. Whether youre charging steep descents, navigating technical climbs, or just out for a day of shredding, the Ripmo AFs modern geometry, versatile suspension compatibility, and thoughtful features make it an excellent choice for riders who want top-tier performance in a rugged, reliable package.
