STEEL HARDTAIL, REDEFINED
Radical modern geometry, featuring an ultra-long reach and super slack head angle, makes the Eccentric 29 perfect for riders who like to go full send. Built from custom-drawn Tange chromoly with integrated gussets we designed in-house, this steel 29er balances strength and agility at just ~2.5 kg. Its engineered to take a beating while delivering pure trail-riding joy.
Decades of dirt jump and hardtail expertise have gone into this frame, making it one of the finest steel hardtails available. Pair it with a 140mm fork and dropper post, and you’ll experience fast, fun riding with that unbeatable hardtail grin.
MAIN FEATURES
- super high-end cromoly frame for 29 and 27.5+ wheels
- Boost 148 dropouts
- designed for Trail & All Mountain riding
- high end multi-butted Tange Eccentric tubing
- modern aggressive geometry with long reach and slack angles
TECHINCAL SPECIFICATIONS
|
|
Material |
Custom butted 4130 cromoly, Tange Eccentric tubes |
Sizes |
3 frame sizes (16, 17.5 & 19.5) |
Recommended fork travel |
130-150mm |
Head tube |
Integrated tapered IS42/IS52 |
Fits forks |
Standard 1-1/8 or tapered 1.5 to 1-1/8 steerer tubes |
Head tube length |
S: 105mm, M: 115mm, L: 125mm |
BB |
Threaded 73mm with ISCG-05 mounts |
Biggest chainring |
BOOST only, up to 32t |
Front derailleur |
Not compatible |
Seat post / clamp |
30.9mm / 34.9mm |
Max seat post insertion |
270mm (S), 300mm (M & L) |
Cable routing |
Stealth cable routing with rubber grommets in seat tube for dropper post |
Maximum tire size |
29 x 2.5, 650B x 3.0 |
Disc brake |
IS-2000 mount, max rotor size: up to 185mm |
Hub spacing |
148x12mm, NS axle included |
Weight |
~2.59kg (M size, without axle) |
Note: Specifications subject to change without notice. Actual colours and design may vary slightly from the images on the website.
